Launch X431 SmartLink C 2.0 HD 24V Trucks 2.0 24V Diagnostic Tool (2024 Update of HD3)
The Launch X431 SmartLink C 2.0 HD 24V Trucks Heavy Duty is a modified version of the Launch X-431 Pro3 which now receives a more powerful tablet than the standard Launch X431 V+ and in-depth diagnostic functions for 24V trucks, buses and offroad machinery.
Autotools.co.za is an authorised LAUNCH distributor
Launch X431 SmartLink C 2.0 HD 24V Trucks & Machinery Main Features:
- Topology mapping lets you visually check the DTCs and all systems’ communication status. (NEW)
- Update of Launch HD3 Module, now with more Brands supported.
- Diagnose commercial vehicles with newly designed SmartLink C V2.0. (NEW)
- Commercial Vehicles Repair & Diagnostics service and solution for trucks, Buses, Construction Vehicles, Agricultural Vehicles, trailers, and Vessels, covering a wide range of commercial vehicles.
- Selecting the service vehicle factory area before accessing the APP reduces the scanning process time, which lets you complete diagnostic jobs faster and more accurately. (NEW)
- Supports automotive communication protocols CAN/CANFD/DoIP and automotive communication standards J2534.
- Comprehensive diagnostic functions and services include reading and clearing DTC, live data streaming, local remote diagnosis and SmartLink remote diagnosis, bi-directional control, wireless software update, coding, etc.
- ADAS HD calibration function increases more revenue. (OPTIONAL)
- The software is available to purchase separately on the Mall at any time. (MALL)
- Built-in repair information and training videos help to track and fix issues fast.
- IP65-rated and 10.1-inch IPS sunlight-readable touch screen with gorilla glass against scratch.
- Toolbox for multiple Add-on Modules supported, including Oscilloscope, Sensorbox, Battery Tester, Videoscope, WIFI Printer, EV Clamp, EM101N, Key Programmer, etc.
If you already own X-431 PRO3 or X-431 PRO5 12V Cars configuration, you can just buy a heavy-duty Smartlink C 2.0 HD module.
- Full comprehensive diagnostic software functions.
- Wide diagnostic software coverage. Accurate test data. Software based on Android, matching with more diagnostic hosts
Launch X431 SmartLink C 2.0 HD 24V Trucks & Machinery Product Features：
Intelligent diagnosis: In the state of networking, it can automatically identify vehicle information and complete rapid diagnosis. It can also check the history record of vehicle maintenance online, which is the first in the industry;
Remote diagnosis:
The self-developed and patented IM remote diagnosis technology of Launch X431 V+ SmartLink C 2.0 Heavy Duty can be quickly accessed remotely through terminals such as mobile phones, tablets, computers, etc., and the network broadband and system resources occupation rate is low;
Diagnostic feedback:
In the process of using the vehicle and function abnormalities under special circumstances, you can feedback the problem to Launch Company, and there will be special technicians to track and handle it;
Maintenance, Repair & Service information:
Launch X431 SmartLink C 2.0 HD 24V Trucks tool covers more than 1600 models, more than 10,000 GB of maintenance database, including online video, circuit diagram, maintenance manual, maintenance cases, operation skills, etc., online inquiry at any time, can also provide detailed fault code help, improve diagnostic efficiency;
Diagnostic record:
Record the local vehicle maintenance record, you can check the vehicle record that the machine has previously diagnosed, and you can quickly enter the system of the vehicle for detection when it is diagnosed again;
Software upgrade:
Supports one-click upgrade of operating system, client, model software and firmware;
Personal Center:
Personal data centre, including my report, my connector, diagnostic connector connection management, connector activation, firmware repair, personal information, modify user password, settings, etc.
Special Functions
Vehicle Coverage of Launch X431 SmartLink C 2.0 HD 24V Trucks Tool
Allison, Ashok Leyland, Astra, Benz, Bendix, Bosch, Bremach, Case, Caterpillar, Credo, Cummins, DAF, Deutz, DFL, Dachai, Delphi, Denso, Detroit, Doosan, Eaton, Eicher, FAW, Flexi-Coil, Ford, Foton, Freightliner, Fuso, Haldex, Higer, Hino, Hyundai, International, Iris Bus, Isuzu, Iveco, JAC, JCB, JMC, John Deere, Kenworth, Kinglong, Knorr, Kobelco, MWM, Machinery, Mack, Mahindra, MAN, Maxxforce, Mercedes, Miller, Mitsubishi, Newholland, Nissan, Paccar, Perkins, Petgerbilt, Renault, SCR, Scania, Sinotrucks, Sprinter, Sterling, Steyr, Sunlong, Tata, Toyota, Trailer, UD, Volvo, WP, Wasco, Western Star, ZF
View full coverage at Launch Official Site
How to Activate Launch X431 SmartLink C 2.0 HD 24V Trucks Diagnostic Tool & Download Software:
If you already have a X431 diagnostic tool for 12V passenger car configuration and intend to extend the diagnostics of commercial vehicles, follow the steps described below to activate the Smartlink C 2.0 HD Module:
- 1. Launch the application, and log in the system using the existing user account of Passenger Vehicle Configuration, and then tap “Personal Center (or )” -> “Activate VCI (or “Activate Connector )”.
- 2. Input the Product S/N and Activation Code, which can be found in the supplied Password Envelope, then tap “Activate” to activate the Smartlink C.
- 3. Tap “Update” to enter update center, tap “Update” to download and install the diagnostic software of Commercial vehicles.
- 4. After the software download is complete, a new “Heavy-duty” tab will appear on the Diagnostic main menu screen.
Launch X431 SmartLink C 2.0 HD 24V Trucks Hardware Specs:
- Operating System: Android 9.0
- CPU: Qualcomm Snapdragon 450, 8-core 1.8GHz
- Battery: 7000mAh rechargeable polymer lithium battery
- Memory: 3GB
- Storage Capacity:32GB (New 2021 Version)
- LCD: 10.1 inch LCD Resolution: 1920*1200 I
- PS Touch Screen: Capacitive Touch Screen
- Cameras: 5.0 mega pixels front and 8.0 mega pixels rear.
- Wi-Fi: 802.11a/b/g/n/ac (2.4GHz / 5GHz) Bluetooth:
- Supported Working Temperature: 0 ~ ℃ 45℃ Storage Temperature: -20 ~ ℃ 70℃
Diagnostic box parameters
CPU: 120MHz Power consumption: ≤3W Working voltage: DC 9-36V Working temperature: -10 ° C ~ 50 ° C Communication method: USB+ Wi-Fi+ Bluetooth Size: 204x110x45 (mm)
OBD Adapters Includes 14pc OBD Adapter Cables, 9pc Electric Control Adapter Cable, Gigabit Ethernet cable for DOIP diagnosis, Double clamp power cord, 4pcs x Fuse, AC250V/5A, φ5*20mm ROHS
