ELS27 is a new diagnostic adapter for Ford/Mazda combining full compatibility with ELM327, high reliability and speed while working with the vehicle network. The device supports work via CAN bus and K-L lines.

The ELS27 v3.0 diagnostic adapter is designed on the basis of the STN2120 chip, which allows you to realize all the functions of the ELM327 adapter, but:

It supports two data buses — HS CAN and MS CAN — without switches and toggle switches;
It works several times faster (up to 10 times, according to the chip developer);
It supports SW CAN bus (used in General Motors cars);
It supports MM CAN bus (used in Focus 3 and Mondeo 4);
It supports firmware update so that any identified issues can be resolved by the developer;
It supports sending multi-line messages;
It has a working Reset NVM (settings reset), so it is almost impossible to disable the adapter programmatically.

Supported programmes you can download to use with ELS27 cable:

“FORScan” for Ford and Mazda vehicles
“FoCCCus” for Ford Focus 3
“ELMConfig” Enable/disable Ford ECU Functions

NB. USE WINDOWS XP SP3 or WINDOWS 7 32 bit version. Some Windows 8 and 10 computers have driver compatibility issues.

FORScan Software updates and functions

+ Added feature
* Improved/changed feature
– Bug fixed/removed feature

2.3.34 beta, 2020-07-05 (download)

+ Vehicle database update
+ Many configuration parameters for different modules and models
+ SYNC GEN1/GEN1.1 configuration parameters
+ Configfuration and programming function “Central Configuration” for Mazda 2/Demio DE 2007MY
+ Configuration and Programming function IPC “Odometer write” (can only increase mileage!) for:

Escape 2020MY
Kuga 2020MY
Transit Connect (North America) 2014-2018 model years
Transit 2020MY
Lincoln Corsair 2020MY+ Service function “Reset all adaptations” for AWD module of 2017+MY vehicles
+ Service functions BCM “Local Interconnect Network New Module Calibration”, (used for rear camera calibration but not only), “Tire Pressure Monitor learning mode”, “Battery Monitoring System Reset”for:
Escape 2020MY
Kuga 2020MY
Transit 2020MY
Lincoln Corsair 2020MY+ Service function RCM “Crash Flag Reset” for:
Escape 2020MY
Kuga 2020MY
Transit 2020MY
Lincoln Corsair 2020MY+ Service functions for ABS/ESP module: “Calibrate Lateral Acceleration Sensor”, “Calibrate Longitudinal Sensor”, “Calibrate Pressure Sensor” , “Calibrate Yaw Rate Sensor” for:
Fiesta 2017 model year
Transit Connect (V408MCA) 2019-2020 model years+ Service functions for ABS/ESP module “Calibrate Roll Rate Sensor” for:
Transit Connect (V408MCA) 2019-2020 model years+ Service function ABS “ABS Service Bleed”, “Calibrate Longitudinal Sensor” for:
Transit (V363 EU) 2.0 TDCi 2016 model year+ Service function ABS “ABS Service Bleed” for:
C-Max Mk2 2.0 Hybrid (PHEV/FHEV) 2013-2018 model years
Focus Mk3/3.5 Electric (BEV) 2012-2017 model years
Fusion 2.0 Hybrid (FHEV/PHEV) 2013-2019 model years
Mondeo (China) 2.0 Hybrid (FHEV/PHEV) 2017-2019 model years
Lincoln MKZ 2.0 Hybrid (FHEV) 2013-2019 model years+ Service function PCM/TCM “Clear Transmission Adaptive Tables” for models with automated transmission before 2005 model year that support it
+ Service function “PATS Programming” for Mondeo Mk2 Duratec-VE 1997 model year
+ Reading VIN for all modules
* improved SYNC GEN recognition (added GEN 1.1 recognition in addition to GEN 1/2/3)
* multiple fixes and improvements in PCM Vehicle ID Block Configuration function
* Improved support for 2020MY models
– security access problems and bugs
– duplicated confirmation dialog in the function Module Configuration (As Built format) in case of “Write All” operation
– bug in PATS Programming->Module Initialization function for Mazda 2/Demio 1.6 Y6
– errors in Vehicle->Configuration text exported to TXT file in case of non-ASCII characters
2.3.33 beta, 2020-05-08 (download)+ Some configuration parameters for different modules and models
+ Configuration and programming procedure TRM “Trailer tow activation” for:
Edge 2015-2020 model year+ Automated loading factory As Built Data in PCM “VID configuration” function
+ Service functions BCM “Local Interconnect Network New Module Calibration”, (used for rear camera calibration but not only), “Tire Pressure Monitor learning mode”, “Battery Monitoring System Reset” for:
Puma 2020 model year+ Service function ABS “ABS Service Bleed” for:
Freestar 2004-2005 model years
Windstar 3.8 V6 2003 model year (with IVD)
Mercury Monterey 2004-2005 model years+ couple of missing OBDII Mode 6 tests for Mazda
* Improved support for some 2020MY models (Transit V408MCA, Expedition, Puma)
* small fixes and improvements in procedure of loading AB and ABT files
– unability to download TRID file (bug appeared in 2.3.32)
– forbidden negative values in service function FSC “Static aiming” for Mazda Skyactiv
– bug in Ignition Key Programming sub-function of PATS programming function for some 1999-2004MY models
– bug obtaining PCM security access in service procedure “Remote Keyless Entry and Start Programming” for Fiesta (North America) 2011-2019 model years
– bug in service function PSCM “Calibrate Steering Angle Sensor” for 2017MY Fiesta and other new models: procedure required KOEO mode instead of KOER
– incorrect recovery vehicle configuration from profile in some rare cases2.3.32 beta, 2020-04-15 (download)+ Vehicle database update
+ Some configuration parameters for different modules and models
+ Configuration and programming functions “Module initialization/relearn vehicle data” for AWD module of 2017+MY vehicles
+ Automated loading factory As Built Data in Configuration functions “Module Configuration (As Built format)”, “Central Configuration”
+ Service procedure “Remote Keyless Entry and Start Programming” (for models with start button, adapter with seamless switching between HS and MS is required) of:
Fiesta (North America) 2011-2019 model years+ Service function “PATS Programming” for:
E-Series 2009-2019 model years+ Service function PSCM “Reset Pull Drift Compensation” for:
F-Series 2011-2013 model years
Mustang 2011-2014 model years
Territory 2011/2014 model years+ Service functions for ABS/ESP module: “Calibrate Lateral Acceleration Sensor”, “Calibrate Longitudinal Sensor”, “Calibrate Steering Angle Sensor” for:
Falcon 2011/2014 model years
Territory 2011/2014 model years+ Service procedure FCIM “Local Interconnect Network New Module Calibration” for:
Falcon 2014 model year
Territory 2014 model year+ some missing PIDs
* Improved support for some new models (2020MY Escape, Puma)
* Corrections in CAN communication procedure for wireless adapters
* Corrections in DPF regeneration procedure (to make it reliable for using in FORScan Lite / with wireless adapters)
* small fixes and improvements in Central Configuration function users interface
– removed incorrect ABS module configuration parameters for 2015MY+ trucks that caused U2200 DTC after change
– incorrect PATS configuration detection in service function “PATS Programming” for:
Ranger 2007-2011 model year
F-Series (P356) 2008-2010 model year
E-Series 2008 model year2.3.31 beta, 2020-03-20 (download)+ ForDiag adapter support
+ Some configuration parameters for different modules and models
+ Service function “Reset pilot injection quantity learned values” for:
Everest 2.2/3.2 TDCi 2015 model year
Focus Mk3.5 1.6 TDCi 2015 model year
Ka/Figo 1.5 TDCi (DV5D) 2015 model year
Kuga 2.0 TDCi (DW10F) 2013 model year
Mondeo Mk5 2.0 TDCi (DW10C) 2015 model year
Galaxy/S-Max 2015 model year+ Service functions “Reset SCR converter Learned Values”, “SCR System Refill Activation”, “Reset Fuel Mass Observer adaptations” for:
Edge 2.0 TDCi 2019-2020 model years
F-150 3.0 Powerstroke 2018-2020 model years
F-Series 2011-2019 model years
Transit 2.0 TDCi 2016 model year+ Service procedure “ABS Service Bleed” for:
Edge 2010 model year
Fiesta (North America) 1.6 EcoBoost 2014 model year (experimental)
Mustang 2005-2010 model years
Lincoln MKX 2010 model year+ Service function ABS “Calibrate Longitudinal Sensor” for:
Fiesta (North America) 2014-2019 model years* fixed some parameters deleted by mistake from Central Configuration
– bug that caused disappearing service function CCM “Calibrate Cruise Control Sensors” for:
Fusion 2013 model year
Mondeo (China market) 2013 model year
Lincoln MKZ 2013 model year2.3.30 beta, 2020-03-07 (download)+ Vehicle database update
+ Configuration and programming functions “Module initialization/relearn from Central Configuration” for PCM and TCM modules of F-Series 2020
+ Configuration and Programming function “Odometer write” (can only increase mileage!) for Explorer 2016-2019 (experimental)
+ Some configuration parameters for different modules and models
+ Service procedure “Remote Keyless Entry and Start Programming” (for models with start button, adapter with seamless switching between HS and MS is required) of:
Escape 2013-2016 model years
Focus Mk3 (North America) 2012-2014 model years
Focus C-Max (North America) 2012-2016 model years+ Service function “Remote Keyless Entry and Start Programming” (equipped with smart cards) of:
Mazda 3 (Europe) 2006 model year
Mazda 3/Axela (Japan) 2006 model year
Mazda 3 (North America) 2007-2009 model years
Mazda 3 (China) 2007 model year
Mazda CX-7 (North America, Japan) 2007-2008 model year
Mazda CX-7 (Europe) 2006 model year
Mazda CX-9 (North America) 2007-2011 model year
Mazda Biante 2008-2012 model year+ Service function “ABS Service Bleed” for:
Explorer 2000/2002 model years
Explorer Sport 2000-2003 model years
Explorer SportTrac 2000-2005 model years
Ranger 2001-2003 model years
Mercury Mountaineer 2000/2002 model years+ Missing PATS module for Explorer SportTrac 2000 model year2.3.29 beta, 2020-02-04 (download)+ Vehicle database update
+ Many configuration parameters for different modules and models
+ Service procedures “Read Fuel Injector correction factors”, “Change Fuel Injector correction factors” for:
Transit (EU) 2.0 TDCi (EcoBlue) 2016 model year
Edge 2.0 TDCi (EcoBlue) 2019-2020 model years+ Support for aftermarket TCU module in:
Explorer 2011-2015 model years
Mustang 2015-2017 model years+ Service function “ABS Service Bleed” for:
Crown Victoria 1998-2000 model years
Explorer 1997-1999 model years
Focus 2000 model year
Ranger 1998-2000 model years
Lincoln Continental 1995-2002 model years
Lincoln Mark VIII 1997-1999 model years
Lincoln Town Car 1998-2000 model years
Mercury Grand Marquis 1998-2000 model years
Mercury Mountaineer 1997-1999 model years+ Service procedure “Headlamp Alignment And Calibration” for Escape 2013-2019, equipped with HCM
+ added missed SCCM module for 2020 F-150
* changed incorrect displaying injector correction factors for Transit Custom 2.0 TDCi (EcoBlue) 2016 model year
– bug in RCM service function “Crash Flag Reset” for Mondeo Mk4 2007 model year
– bug in processing results of some service routines
– bug in displaying and calculation of some parameters (such as DIST_LAST_PDF, DIST_LAST_DeSOx, DIST_LAST_DeNOx etc)
– bug in PATS Programming function (unability to run Module Initialization for models without chipped keys) of:
Ranger 2007-2011 model year
F-Series (P356) 2008-2010 model year
E-Series 2008 model year- incorrect work of service procedure “Reset Fuel Injector Adaptation” for Transit Custom 2.0 TDCi 2016 model year
– TIMED PATS method support for Focus/C-Max 2008 model year (that seems to be not really supported by modules)
– UBP bus support for Elm327 compatible adapters (as none of them really can work with this bus). Now UBP bus is only supported for Ford VCMII adapter2.3.28 beta, 2019-12-30 (download)+ Some PCM configuration parameters for Mondeo Mk5 with 1.5 TDCi StgVI engine
+ Anti-Noise Control and Engine Sound Enhancement configuration parameters for DACMC module of:
Edge 2015-2020 model years
Expedition 2018-2020 model years
F-150 2015-2020 model years
Fusion 2014-2020 model years
Galaxy/S-Max 2015 model year
Mondeo Mk5 2015 model year
Mustang 2015-2020 model years
Lincoln MKC 2015-2019 model years
Lincoln MKZ 2014-2020 model years
Lincoln Navigator 2018-2020 model years+ Support for TCU module in 2016-2018 F-Series
– crash bug at the end of loading vehicle configuration in some cases2.3.27 beta, 2019-12-19 (download)+ Vehicle database update
+ Configuration and programming function “Module initialization/relearn from Central Configuration” for ABS module of:
Galaxy/S-Max 2006/2010 model years
Mondeo Mk4 TDCi 2007/2011 model years+ some DDM/PDM configuration parameters for:
F-150 2015+ model years
F-Series 2017+ model years
Fusion 2013+ model years
Galaxy/S-Max 2015 model year
Mondeo Mk5 2015 model year
Lincoln MKZ 2013+ model years+ Some BdyCM configuration parameters for:
Ecosport 2018 model year
Explorer 2020 model year
Fiesta 2017 model year
Focus Mk4 2018 model year
F-Series 2020 model year
Transit/Tourneo Custom 2019 model year
Lincoln Aviator 2020 model year+ Configuration parameter “Console Clock” and “Park Aid Control” to ACM module of:
Falcon/Fairmont/Fairlane BA/BF 2003-2006 model years+ Some configuration parameters to different modules and models
+ Test “OCS System Zero Weight Test” and service function “OCS System Reset” for:
Edge 2010-2014 model years
F-150 2009-2014 model years
Flex 2010-2019 model years
Fusion 2009-2012 model years
GT 2017-2020 model years
Taurus 2010-2019 model years
Lincoln MKS 2010-2016 model years
Lincoln MKT 2010-2019 model years
Lincoln MKX 2010-2015 model years
Lincoln MKZ 2009-2012 model years
Mercury Milan 2009-2011 model years+ Service function “OCS System Reset” for:
C-Max (North America) 2013-2018 model years
Ecosport 2018 model year
Edge 2015-2020 model years
Escape 2013-2019 model years
Explorer 2011-2019 model years
F-150 2015-2020 model years
Fiesta (North America) 2014-2019 model years
Focus Mk3 (North America) 2012-2018 model years
Fusion 2015-2020 model years
Galax/S-Max 2015 model year
Kuga 2017-2018 model years
Mondeo (China) 2017-2019 model years
Mustang 2015-2020 model years
Ranger/Everest 2015 model year
Transit 2018-2019 model years
Transit Connect (North America) 2014-2019 model years
Lincoln Continental 2017-2020 model years
Lincoln MKC 2015-2019 model years
Lincoln MKZ 2013-2020 model years+ Service procedures “Read Fuel Injector correction factors”, “Change Fuel Injector correction factors”
Ranger/Everest 2.2 TDCi 2015 model year+ Service functions IPMA “Lane Departure Warning System Camera calibration” of:
Fiesta 2017 model year
Focus Mk4 2019 model year
Ranger/Everest 2018-2019 model years
Transit Connect 2019+ model years+ Service function for ABS/ESP module “Calibrate Yaw Rate Sensor” of:
F-Series 2011-2016 model years
Mustang 2011-2014 model years+ Service procedure “Headlamp Alignment And Calibration” for the following vehciles, equipped with HCM module 6M21-13K031-*:
Galaxy/S-Max 2006/2010 model years
Mondeo Mk4 TDCi 2007/2011 model years+ Service function “Remote Keyless Entry and Start Programming” (equipped with smart cards) of:
Mazda 2 (Japan Market) 2002-2005 model years
Mazda 6 (European market) 2002-2005 model years
Mazda 6 (General market) 2.3 L3 2003-2008 model years
Mazda Atenza 2.3 L3 2002-2005 model years+ Service functions for ABS+DSC module “Calibrate Lateral Acceleration Sensor”, “Calibrate Pressure Sensor” of:
Mazda 3/Axela BK with DSC 2003-2006 model years
Mazda 3 BK (US Market) with DSC 2004-2009 model years
Mazda 5/Premacy with DSC 2005-2007 model years
Mazda 5 (US Market) with DSC 2006-2010 model years+ Service function for ABS without DSC module “Calibrate forward G Sensor” of:
Mazda Axela 4WD 2006 model year
Mazda Premacy 4WD 2005-2007 model years
Mazda 5/Premacy 2010-2013 model years+ Service function “Reset EGR Valve Adaptations” for:
Everest TDCi 2015 model year
Galaxy/S-Max 2.0 TDCi 2015 model year
Ka/Figo 1.5 TDCi 2015 model year
Mondeo Mk5 1.6/2.0 TDCi 2015 model year+ Support for extended set of STN commands (ELS27, OBDLink EX, OBDLink MX+, other products based on STN chip with firmware v3.4.x+)
* Improvement in service function “Reset pilot injection quantity learned values” (show more detailed information if procedure has not been started)
* fixes and improvements in FSC Dynamic Aiming procedure for Mazda Skyactiv 2017-2019 model years
* Improvements in Configuration and Programming function “Odometer write”
* Improvements in VBF downloading procedure from Motorcraft site
* Improvements in SBL loading procedure
– fixed bug: unability to write module configuration (As-Built data) to some CAN modules, for example RCM in Ranger 2.3 Duratec-HE 2009
– fixed bug: added disappeared BdyCM PATS Programming function for Explorer 2011-2015 and other models2.3.26 beta, 2019-10-30 (download)+ Vehicle database update
+ IPC and BdyCM configuration parameters for:
Escape 2020 model year
Transit / Tourneo Custom 2016 model year+ Some configuration parameters to different modules and models
+ Configuration and Programming function “Odometer write” (can only increase mileage!) for :
Kuga 2017/2018 model years
Transit / Tourneo Custom 2016 model year+ Service functions IPMA “Lane Departure Warning System Camera calibration” for:
Fusion 2019-2020 model years+ Service procedure “Headlamp Alignment And Calibration” for the following vehciles, equipped with HCM module:
Explorer 2011-2019 model years
Focus MK3.5 2015 model year
Galaxy/S-Max 2015 model year
Transit 2016-2018 model years
Lincoln MKC 2015-2019 model years+ Service procedure “DPF Static Regeneration” for:
Transit/Tourneo Connect 1.5 TDCi 2019 model year+ Service function “ABS Service Bleed” for:
F-Series (F131, P356) 2005-2010 model years+ Service procedures “Read Fuel Injector correction factors”, “Change Fuel Injector correction factors”, “Reset the Turbocharger Accumulated Soot Value” for:
Everest 3.2 TDCi 2015 model year
Ranger 3.2 TDCi 2015 model year+ Service procedure “State of Charge Correction” for:
Focus Mk3/3.5 Electric (BEV) 2012-2018 model years+ Service procedure “Reset MAF Sensor Adaptation”, “Reset the Turbocharger Variable Vane Position Sensor Adaptation” for:
B-Max 1.5/1.6 TDCi 2012 model year
Fiesta 1.4/1.6 TDCi 2008 model year
Focus/C-Max 1.5/1.6/2.0 TDCi 2011/2015 model years
Galaxy/S-Max 1.6/2.0 TDCi 2006/2010 model years
Ka 1.5 TDCi 2015 model year
Kuga 1.5/2.0 TDCi 2008/2013/2017 model years
Mondeo Mk4 1.6/2.0 TDCi 2007/2011 model years
Transit 2.0/2.2 TDCi 2014/2016/2017 model years
Transit Connect 1.6 TDCi 2014 model year
Ranger / Mazda B-Series / Courier 2.2/3.2 TDCi 2011/2015 model years
Mazda 2/Demio 1.6 Y6
Mazda 3/Axela 1.6 Y6
Mazda 5/Premacy 1.6 Y6+ Service procedure “Reset the Turbocharger Variable Vane Position Sensor Adaptation” for:
Ecosport 1.5 TDCi 2012/2014/2018 model years
Everest TDCi 2015 model year
Mondeo Mk5 1.6 TDCi 2015 model year
Transit 1.6 TDCi 2012/2014/2016/2017 model years
Transit Courier 1.5 TDCi 2014 model year+ Service procedure “Reset the water in fuel warning indicator”, “Reset the Intake Air Throttle Valve Learned Values” for:
Everest TDCi 2015 model years
Focus/C-Max Mk3.5 1.5/1.6/2.0 TDCi 2015 model year
Galaxy/S-Max 2.0 TDCi 2015 model year
Kuga Mk2 2.0 TDCi (DW10F) 2013 model year
Mondeo Mk5 1.6/2.0 TDCi 2015 model year+ Service procedure “Reset the water in fuel warning indicator” for:
Ecosport 1.5 TDCi 2012/2018 model years+ Service procedure “Reset the Intake Air Throttle Valve Learned Values” for:
Ranger TDCi 2011/2015 model years+ Service procedures “Reset oil change indicator” for:
Ka 1.5 TDCi 2015 model year+ Service functions for ABS/ESP module: “Calibrate Lateral Acceleration Sensor”, “Calibrate Longitudinal Sensor”, “Calibrate Pressure Sensor”, “Calibrate Yaw Rate Sensor” for:
Demio/ Mazda 2 DE 2007-2014 model years
Axela/Mazda 3 BL 2009-2013 model years
Premacy/Mazda 5 2010-2013 model years+ Service functions PSCM “Calibrate Steering Angle Sensor”, “Reset Pull Drift Compensation” for:
Escape 2016-2019 model years
Focus Mk3/3.5 (North America) 2012-2019 model years
Kuga 2017/2018 model years+ Support for OBDII Mode 6 monitors “Boost Pressure Control Monitor”, “NOx Adsorber Monitor”, “NOx Catalyst Monitor”, “Thermostat Monitor”
+ Support SCR/NOx and some other missing PIDs for Ranger 3.2 TDCi 2015 model year
+ Support for TCU module in 2015-2016 F-150
– bug in “PATS Programming” function for:
Fiesta (North America) 1.6 TiVCT 2014-2015 model years- freezing on reading IPC As Built Data in Mazda SkyActiv
– incorrect processing fractional configuration parameters change2.3.25 beta, 2019-09-28 (download)+ Vehicle database update
+ Configuration and programming function “Central Configuration” for Mazda SKYACTIV
+ Configuration and programming functions “Module initialization/relearn vehicle data” for PCM and TCM modules of:
Ecosport 2018 model year
Expedition 2018-2019 model years
Explorer 2020 model year
Fiesta 2017 model year
Focus Mk4 2019 model year
Lincoln Navigator 2018-2019 model years+ Configuration parameter “Engine Sound Enhancement” (enable/disable) for ACM modules of:
Focus Mk3.5 (ACM F1BT-18C815, F1ET-18C815)+ Service function “Remote Keyless Entry and Start Programming” (equipped with smart cards) for:
Mazda 5 (All markets) 2005-2007 model years
Mazda MX-5 (All markets) 2005-2010 model years+ Service function RFA “PATS Programming” (for Intellectual Access Keys, requires adapter with MS-CAN support) for:
Edge 2011-2014 model years
Expedition 2015-2017 model years
Explorer 3.5 TiVCT 2011 model year
Explorer 2012-2015 model years
Flex 2013-2017 model years
Taurus 2013-2017 model years
Lincoln MKS 2013-2016 model years
Lincoln MKT 2013-2017 model years
Lincoln MKX 2011-2015 model years
Lincoln Navigator 2015-2017 model years+ Service function “ABS Service Bleed” for:
Expedition 2015-2017 model years
F-150 2009-2014 model years
Ranger 2010-2011 model years
Lincoln Navigator 2015-2017 model years+ Service function ABS “Calibrate Steering Angle Sensor”, “Calibrate Lateral Acceleration Sensor” “Calibrate Longitudinal Sensor”, “Calibrate Pressure Sensor”, “Hydraulic Control Unit Inlet Valve Calibration”, “Hydraulic Control Unit Isolation Valve Calibration” for:
Focus Mk4+ Service functions PBM “Apply and Release Calibration (Assembly Test)”, “Enter Electric Parking Brake Maintenance Mode”, “Exit Electric Parking Brake Maintenance Mode” for:
Galaxy/S-Max 2006/2010 model years
Mondeo Mk4 2007/2011 model years+ Service functions EPB “Apply and Release Calibration (Assembly Test)”, “Enter Electric Parking Brake Maintenance Mode”, “Exit Electric Parking Brake Maintenance Mode”, “Apply Electrical Parking Brake”, “Release Electrical Parking Brake”, “Apply left EPB actuator”, “Release left EPB actuator”, , “Apply right EPB actuator”, “Release right EPB actuator”:
Focus Mk4+ Service functions “Shift Fork System Learn” and “Clutch System Learn” for Powershift DCT450 of:
Focus/C-Max Mk2 2008 model year+ Service function “PATS Programming” for:
Mondeo Mk2 1.8 Endura-DE 1997 model year+ VIN configuration parameter of ABS module for Focus Mk4, for RCM module Fiesta 2008 model year
+ Some module configuration parameters for different modules and models
* Fixes and improvements in Central Configuration function (added missing parameters and values, fixed bugs etc) for Focus, C-Max, Kuga, Escape, Mondeo, S-Max, Ranger, Everest, Transit and Transit Connect family, added missing support for Transit Courier (B460)
* Fixes and improvements in adapter communication procedure for OBDLink MX (STN1151)
* Fixes and improvements in CAN communication procedure
* Fixes and improvements in error processing for some service procedures (provide more informative output in case of failure)
– incorrect connection to Focus Mk4 ST (2.3L Ecoboost)
– error exporting profile if the file path contains non-ASCII characters
– bug in gaining security access procedure in service function “PATS Programming” for:
Transit (North America) 2015-2016 model years- bug writing module configuration on some models 2005-2008 model years
– unability to write As Built Data for some modules of new models (Expedition 2018-2019, Explorer 2020, Focus Mk4, Fiesta Mk8, Ecosport 2018+)
– bug in RCM “Crash Flag Reset” service function for Explorer 2011-2015 model years
2.3.24 beta, 2019-08-05 (download)+ Vehicle database update
+ Some BdyCM module configuration parameters for:
Edge 2015-2019 model years
Expedition 2018-2019 model years
Lincoln Navigator 2018-2019 model years
Ka/Figo 2018 model year+ Some IPC module configuration parameters for:
Edge 2015-2019 model years
Expedition 2018-2019 model years
Explorer 2020 model year
Kuga/Escape 2017+ model years
Lincoln Navigator 2018-2019 model years+ Some APIM/SYNC3 configuration parameters
+ Configuration and programming procedure “Central configuration” for:
Escape 2019 model year
Transit (V363, North America market) 2019 model year+ Configuration and Programming function “Odometer write” (can only increase mileage!) for :
Explorer 2020 model year
Ranger 2011 model year
Ranger 2015-2019 model years (experimental)+ Configuration parameter “Engine Sound Enhancement” (enable/disable) for ACM modules of:
Ecosport 2018 model year
Fiesta 2017 model year
Focus Mk4 2018 model year
Ka/Figo 2018 model year+ Service function “PATS Programming” for:
Transit (North America) 2015-2016 model years+ Service procedure “DPF Static Regeneration”, “Reset the Diesel Particulate Filter Learned Values”, “Reset Differential Pressure Sensor Learned Values” for:
Everset 2.2/3.2 TDci 2015 model year
Mondeo 5 1.6/2.0 TDCi 2015 model year
S-Max 2.0 TDCi 2015 model year+ Service functions BdyCM “Local Interconnect Network New Module Calibration”, (used for rear camera calibration but not only), “Tire Pressure Monitor learning mode”, PSCM “Calibrate Steering Angle Sensor”, RCM “Crash Flag Reset” for:
Expedition 2018-2019 model years
Explorer 2020 model year
Lincoln Navigator 2018-2019 model years+ returned back “Module initialization/relearn vehicle data” function for Mazda Skyactiv mistakenly removed in previous release
* fixes and improvements in configuration and programming procedure “Trailer tow activation”
* improvements in service function EPS “Calibrate Steering Angle Sensor” for Mazda 6 GH (after facelift): added important information about initial conditions. Thanks to Alexander (lightning)
– crash bug during connection to diesel cars with FIP/ICU modules (Focus/Mondeo/Transit 1999-2005)
– unability to write DDM/PDM As Built Data for:
Ecosport 2018 model year
Expedition 2018-2019 model years- unability to write IPC As Built Data for:
Focus Mk4 2019 model year (May-July)- bug in parsing some *.AB files2.3.23 beta, 2019-06-29 (download)+ Vehicle database update
+ Several PCM module configuration parameters for new models with 2.0 TDCi engine:
Mondeo Mk5 2.0 TDCi 2015 model year
Galaxy/S-Max 2.0 TDCi 2015 model year
Transit/Tourneo Custom 2.0 TDCi 2016 model year+ Some BdyCM configuration parameters for:
Edge 2011-2014 model years
Escape 2013-2019 model years
Expedition 2015-2017 model years
Explorer 2011-2015 model years
F-150 2011-2014 model years
Focus 2011-2019 model years
F-Series (P473) 2011-2016 model years
Flex 2013-2019 model years
Kuga 2013-2019 model years
Taurus 2013-2019 model years
Lincoln MKS 2013-2016 model years
Lincoln MKT 2013-2019 model years
Lincoln MKX 2011-2015 model years
Lincoln Navigator 2015-2017 model years+ Some IPC module configuration parameters for:
Kuga/Escape 2017+ model years
F-150 2011-2014 model years+ Configuration and Programming function “PCM Vehicle ID block configuration” for some Ford and Mazda PCMs (experimental!), for example it works for Mazda 3 BL 1.6 Z6
+ Fuel Tank Size configuration parameters (in liters and gallons) to IPC module of:
F-150 2015-2019 model years
F-Series 2016-2019 model years+ Configuration and programming functions “Module initialization/relearn vehicle data” for ALL modules that may use Central Configuration + Service function RCM “Crash Flag Reset” for:
Transit V363 (EU) 2014-2018 model years
Transit V363 (NA) 2018-2019 model years+ Configuration and programming function ABS “Reset auxiliary Vehicle ID” (required when if new ABS module is installed) for:
Focus Mk2/C-Max 2003-2008 model years
Kuga Mk1 2008 model year+ Support for “large” As Built Data blocks (like in 2018 IPMB) and “big” block numbers (like 7E0-162-..)
+ Service function “PATS Programming” for Falcon FG 2008-2010 model years (fixed, tested and returned back to release)
+ Service function “ABS Service Bleed” for:
F-Series (P473 platform) 2011-2016 model years
Mustang 2011-2014 model years* updates in service procedures for newest (2018+ MY) models
* Fixes and improvements in CAN communication procedure
* Fixes and improvements in Central Configuration function for Fiesta family (Fiesta, Ecosport, B-Max…), added missing parameters like My Key, ASL etc
* Fixed not correctly working functions “Calibrate Yaw Rate / Lateral Acceleration Sensor”, “Calibrate Brake Booster / Steering Angle Sensor” for:
Lincoln LS 2003-2006 model year- missing decoding for error 88 in function “Fuel Injector Pilot Correction Learn” for:
Transit 2.2/2.4/3.2 TDCi 2006 model year- bug in Central Configuration function: unability to write configuration after loading *.ab or *.cct file
– Problems with writing As Built Data to RCM module in Ford Escape/Mazda Tribute 2008
– Problems with writing As Built Data to some modules in Focus Mk4
– bug in sending commands for some Output Control parameters2.3.22 beta, 2019-05-11 (download)+ Vehicle database update
+ Configuration and Programming function “Odometer write” (can only increase mileage!) for :
Transit Connect 2019 model year+ Several PCM module configuration parameters for new models with 1.5 TDCi engine:
Ecosport 1.5 TDCi 2018 model year
Fiesta 1.5 TDCi 2017 model year
Focus Mk4 1.5 TDCi 2018 model year
Transit Connect (EU) 1.5 TDCi 2014 model year
Transit Connect 1.5 TDCi 2019 model year+ Some BCM module configuration parameters for:
Transit Connect 2019 model year+ Some IPC module configuration parameters for:
EdgeGalaxyS-Max (EU) 2015 model year
F-150 2015-2019 model years
F-Series 2016-2019 model years
Fusion 2013-2019 model years
Mondeo (EU) 2015 model year
Transit Connect 2019 model year
Lincoln MKZ 2013-2019 model years+ Service functions “Local Interconnect Network New Module Calibration”, (used for rear camera calibration but not only), “Tire Pressure Monitor learning mode”, “Calibrate Steering Angle Sensor” for:
Transit Connect 2019 model year+ Service function “CEI Lock Configuration” for BCM module of:
Edge 2011-2014 model years
EdgeGalaxyS-Max (EU) 2015 model year
Escape 2013-2019 model years
Escort 2015/2018 model years
Everest 2015 model year
Expedition 2015-2017 model years
Explorer 2011-2019 model years
F-150 2011-2019 model years
Focus/C-Max (North America) 2012-2018 model years
Flex 2013-2019 model years
Fusion 2013-2019 model years
F-Series 2011-2019 model years
Ford GT 2017-2019 model years
Ka/Figo 2015 model year
Kuga 2017 model year
Mondeo (China) 2013-2019 model years
Mondeo (EU) 2015 model year
Mustang 2015-2020 model years
Ranger 2015 model year
Taurus 2013-2019 model years
Transit (North America) 2018-2019 model years
Transit Connect (North America) 2014-2018 model years
Lincoln Continental 2017-2019 model years
Lincoln MKC 2015-2019 model years
Lincoln MKS 2013-2016 model years
Lincoln MKT 2013-2019 model years
Lincoln MKX 2011-2019 model years
Lincoln MKZ 2013-2019 model years
Lincoln Navigator 2015-2017 model years+ IPC, BCMii, TRM, PAM, SODL/SODR, FCDIM trailer tow configuration parameters for:
Ranger 2015-2019 model years
Everest 2015-2019 model years+ Configuration and programming procedure “Trailer tow activation” for:
Ranger 2018-2019 model years
Everest 2018-2019 model years+ Service function RCM “Crash Flag Reset” for:
Transit Custom (EU) 2012 model year
Transit Connect 2019 model year+ Service function for EPB “Apply and Release Calibration (Assembly Test)” for:
Edge 2015-2019 model years
Escape 2017-2019 model years
F150 2015-2019 model years
Fusion 2013-2019 model years
Galaxy/S-Max 2015 model year
Kuga 2017-2019 model years
Mondeo 2015 model year
Mondeo (China) 2017-2019 model years
Taurus 2016 model year
Lincoln Continental 2017-2019 model years
Lincoln MKC 2015-2019 model years
Lincoln MKX 2016-2019 model years
Lincoln MKZ 2013-2019 model years+ Service function “Enter Electric Parking Brake Maintenance Mode” and “Exit Electric Parking Brake Maintenance Mode” for:
F150 2015-2019 model years* blocked possibility to run several instances of FORScan on the same PC at once
– sporadic GUI freezing
– service function “PATS Programming” for Falcon FG 2008-2010 model years
– unability to connect to some old Mazda (bug appeared in core 2.3.20)
– bug in service procedure “Reset Differential Pressure Sensor learned values” for:
Focus/C-Max 2.0 TDCi 2008 model year- false detection of some modules on some models with J2534 adapters2.3.21 beta, 2019-03-30 (download)+ Vehicle database update
+ Configuration and Programming function “Odometer write” (can only increase mileage!) for :
Ecosport 2017+ model year
Fiesta 2017+ model year
Focus Mk4 2018 model year+ IPC module configuration parameters for:
Flex 2013-2019 model years
Taurus 2013-2019 model years
Lincoln MKS 2013-2016 model years
Lincoln MKT 2013-2019 model years+ Some SCCM module configuration parameters for:
Ecosport 2017+ model year
Fiesta 2017+ model year
Focus Mk4 2018 model year+ PDM/DDM module configuration parameters for:
Focus Mk2/C-Max 2004-2012 model years
Kuga Mk1 2008-2013 model year+ Service function RCM “Crash Flag Reset” for:
Ecosport 2017+ model years
Escape 2013+ model years (experimental!)
Explorer 2011-2015 model years
Fiesta 2017+ model year
Focus Mk4 2018 model year
Kuga 2013+ model years (experimental!)+ Service function “Read Factory Keyless Entry code” for:
F-150 2004-2008 model years (only with VCMII adapter that supports UBP bus)
Lincoln Mark LT 2006-2008 model years (only with VCMII adapter that supports UBP bus)+ Service function FSC “Static aiming” for:
Mazda Skyactiv all model years+ Service function FSC “Dynamic aiming” for:
Mazda Skyactiv 2017-2019 model years+ Service functions IPMA “Lane Departure Warning System Camera calibration” for:
F-150 2018 model year (IPMA with part numbers JL3T-19H406-*)
F-Series 2018-2019 model years
Mustang 2018-2019 model years+ Service function VDM “Ride Height Calibration” and Test functions VDM “Accurate Trim Test”, “Pneumatic Test” for the following models with pneumatic suspension:
Expedition 5.4L 3V 2005-2006 model years
Lincoln Navigator 5.4L 3V 2005-2006 model years+ Checksum test for injectors’ QA code in service procedure “Change Fuel Injector correction factors” for:
F-Series Super Duty 6.7 Powerstroke 2011-2018 model years
F-650/F-750 6.7 Powerstroke 2016-2018 model years+ Service function PSCM “Calibrate Steering Angle Sensor” for:
Ecosport 2017+ model year
Fiesta 2017+ model year
Focus Mk4 2018 model year+ Service function BCM “Local Interconnect Network New Module Calibration” (used for rear camera calibration but not only), “Tire Pressure Monitor learning mode” for:
Ecosport 2017+ model year
Fiesta 2017+ model year
Focus Mk4 2018 model year+ Support for PCM of Ecosport (EU) 1.5 TDCi StgVI 2018 model year
+ Missing PIDs for PCM of Ecosport (EU) 2018 model year
+ FORScan version and vehicle information to the main window header
* fixes and improvements in configuration and programming procedure “RCM Module initialization/relearn vehicle data” for:
Transit (EU market) 2006 model year* Fixes and improvements in servce function CCM “Calibrate Cruise Control Sensors” for correct support of 2018-2019 model years CCM
* Small GUI performance optimization
– bug in J2534 ISO15765 protocol support: not counting limit of max 10 flow filters on some adapters like OpenPort 2.0
– bug writing As Built Data on IPC module of some models (appeared in v2.3.20).2.3.20 beta, 2019-02-08 (download)+ Vehicle database update
+ Configuration and Programming function “Odometer write” (can only increase mileage!) for :
F-150 2015-2019 model years
F-Series 2017-2019 model years
Mustang 2015-2019 model years+ Configuration and programming function for PCM/TCM “Module initialization/relearn vehicle data” for:
Ranger/Everest 2018 model year+ Service function PCM “Reset All Adaptations” for:
Ecosport 1.5 TiVCT 2012 model year
Ecosport 1.5 TDCi 2018 model year
Everest 2015 model year
Fiesta 1.5 TiVCT 2008 model year
Focus Mk3.5 1.6 Duratec/1.6 TDCi/2.0 EcoBoost 2015 model year
Kuga Mk2/2.5 1.5 Ecoboost/2.5 IVCT 2013/2017 model years
Transit Courier 1.0 Ecoboost 2014 model year+ Some configuration parameters
+ Service functions PCM “EGR Initialization”, “ETB Initialization” and “Turbocharger Initialization”for:
Mazda models with SkyActive-D 2.2 SH+ Service functions ABS “Inlet Valve Calibration”, “Isolation Valve Calibration” for:
Edge 2015-2019 model years
Escape 2017-2019 model years
Explorer 2016-2019 model years
Fiesta (North America Market) 2014-2019 model years
Focus (North America Market) 2015-2019 model years
Fusion 2013-2019 model years
Galaxy/S-Max 2015 model year
Kuga 2017 model year
Mondeo Mk5 2015 model year
Mustang 2015-2019 model years
Lincoln Continental 2017-2019 model years
Lincoln MKC 2015-2019 model years
Lincoln MKX 2016-2019 model years
Lincoln MKZ 2013-2019 model years+ Service functions DDM “Power Window Initialization (driver’s side)”, PDM “Power Window Initialization (passenger’s side)” for:
Escape 2013-2019 model years
Focus/C-Max 2012-2018 model years
Fusion 2017-2019 model years
Kuga 2013/2017 model years
Mondeo (China market) 2017-2019 model years
Transit Connect (North America) 2016-2018 model years
Lincoln Continental 2017-2019 model years
Lincoln MKZ 2017-2019 model years+ Service function “ABS Service Bleed” for:
E-Series 1997-2005 model years
Excursion 2000-2005 model years
Expedition 1997-2000 model years
F-150 (F96 platform) 1997-2005 model years
F-150 SuperCrew (P225 platform) 2001-2003 model years
F-250 Light Duty (F102 platform) 1997-2000 model years
F-Series (F131 platform) 1997-2004 model years
Lincoln Blackwood 2002-2003 model years
Lincoln Navigator 1998-2000 model years* fixes and improvements for CAN communication procedure for STN1170/2120/2255 chip
* Improvements in service function “ABS Service Bleed” for:
Escape Hybrid 2.3 HEV 2005-2008 model years
Mercury Mariner Hybrid 2.3 HEV 2005-2008 model years- unability to write IPC and SCCM configuration for some Fiesta/EcoSport/Focus 2018+ models
– failure in service function PCM/TCM “Clear Transmission Adaptive Tables” on some models2.3.19 beta, 2018-12-25 (download)+ Vehicle database update
+ Support for OBDLink MX+ adapter (proper recognition of new STN chip)
+ Service function “PATS Programming” (experimental!) for:
Falcon FG 2008-2010 model years+ Service functions “Shift Fork System Learn” and “Clutch System Learn” for Powershift DCT450 of:
Focus/C-Max Mk3/3.5 2011-2015 model years
Galaxy/S-Max 2006-2015 model years
Kuga Mk1 2008 model year
Kuga Mk2/2.5 2013-2017 model years
Mondeo Mk4/Mk5 2007-2015 model years+ Service functions “The installation of a new automatic transmission with the original TCM”, “The removal and installation of the selector lever or the selector lever cable”, “Transmission fluid drain and refill”, “The installation of a new TCM”, “The installation of a new automatic transmission with a new TCM” for TCM module of:
Galaxy/S-Max with automated transmission 450 2006/2010 model years
Mondeo Mk4 with automated transmission 2007/2011 model years+ Service functions “Reset all adaptations”, “Neutral Position Learning”, “Reset the transmission fluid degradation counter” for TCM module of:
Kuga Mk1 with automated transmission 2008 model year+ Service procedures “Reset the Diesel Particulate Filter Learned Values”, “Reset Differential Pressure Sensor Learned Values” for:
Ecosport 1.4/1.5 TDCi Stage V/Stage VI 2012/2014/2018 model years
Fiesta 1.5/1.6 TDCi Stage V 2013 model year
Transit Connect 1.6 TDCi Stage V 2014 model year
Transit Courier 1.5/1.6 TDCi Stage V 2014 model year+ Configuration and Programming function “Odometer write” (can only increase mileage!) for :
Fusion 2013+ (only for Mondeo or Lincoln MKZ cluster installed)
Lincoln MKZ 2013++ Service function “ABS Service Bleed” for:
Transit 2006 model year (without TCS/ESP)+ Some missing modules and parameteres for Ranger/Everest 2018 model year
+ Support for HSWM module (aftermarket) for:
Edge 2011-2015 model years+ Many configuration parameters
* improvements in reading voltage function used in Configuration and Programming procedures
* fixes and improvement to the service procedure “DPF Static Regeneration” for F-Series Super Duty 6.7 Powerstroke 2011-2018 model years: parameters that required to be in a specified range (EGT, ECT, FLI etc) are now displayed with color (green if a parameter is in range and red if a parameter is out of range)
* changed conversion formula from volts to percents for Turbocharger Variable Vane Actuator Position for 2.0 TDCi engines of:
Focus/C-Max 2008 model year
Galaxy/S-Max 2006/2010 model years
Mondeo Mk4 2007/2011 model years- Unability to write IPC configuration for Fiesta/Ecosport 2018 model year, Focus Mk4 2019 model year
– Unability to write RCM configuration for Expedition 2018 model year
– bug in reading As Built Data for DSP module Focus Mk3
– bug in calculating some DMR PIDs
– some visual bugs2.3.18 beta, 2018-10-19 (download)+ Configuration and Programming function “Odometer write” (can only increase mileage!) for:
C-Max/Focus Mk2 2003/2008 model years
Ecosport 2003-2011 model years
Kuga Mk1 2008 model year
Transit Connect 2007/2009 model years+ Configuration and programming function for PCM/TCM “Module initialization/relearn vehicle data” for:
Expedition 2018
Lincoln Navigator 2018- crash bug in case of subsequent connects in some cases
– few bugs in processing J2534 ISO15765 requests
– bug in Module Configuration functions for some models (appeared in 2.3.17 beta3)
– ignition cycle dialog on some old Mazda models that don’t really need it
– missing LFT1 PID on some models2.3.17 beta3, 2018-10-05 (download)- some bugs2.3.17 beta2, 2018-09-30 (download)- Crash bug on connect & modules check for some models
– Errors in processing PCM KOER self-tests for Powerstroke engines2.3.17 beta, 2018-09-25 (download)+ Vehicle database update
+ Configuration and programming procedure “Trailer tow activation” for:
Ranger 2015 model year
Everest 2015 model year
Focus Mk3/3.5 (EU) 2011-2015 model years
Kuga Mk2/2.5 (EU) 2013-2017 model years
Mondeo Mk5 (EU) 2015 model year
Transit (EU) 2016-2017 model years+ Service function “Calibrate AdvanceTrac/IVD” for:
Expedition 2005-2006 model years
Lincoln Navigator 2005-2006 model years+ Service function “IPMB Local Interconnect Network New Module Calibration” (used for forward camera calibration) for:
Mustang 2015-2019 model years+ Support for ISO15765 protocol in J5234 Passthru adapters. User now can choose between hardware (adapter) and software (FORScan) ISO15765 implementation
+ Service function “PATS Programming” (only for standart PATS, doesn’t work for cars with keyless system!) for:
Flex 3.5 Ecoboost 2010-2012 model years+ FORScan now doesn’t allow to swtich to a sleep mode if connection to vehicle is established
+ Some configuration parameters
* fixes and improvements in CAN communication procedure for ELM327 adapters
– crash on connect & modules check for some models
– incorrect vehicle conditions check (ECT, IAT, FLT) in service function “Injector Calibration” for Mazda SKYACTIV-D
– errors in processing “KOER Switch Self Test” for Powerstroke engines
– bug in service function “Reset the Exhaust Gas Temperature Learned Value” for in Focus Mk2 1.6 TDCi StgV
– disappearing “PCM Vechile ID block configuration” function after first connect2.3.16 beta, 2018-07-04 (download)+ Vehicle database update
+ Ability to export and import vehicle profiles
+ Configuration and programming procedure RVM/BSM “Module initialization/relearn vehicle data” for:
Mazda SKYACTIV+ Configuration and Programming function “PCM Vechile ID block configuration” for certain PCMs (test mode!)
+ Service function “PATS Programming”for:
Lincoln Mark VIII 1997-1998 model years+ Service procedure “DPF Static Regeneration” for:
Ecosport 1.4/1.5 TDCi Stage V/Stage VI 2012/2014/2018 model years
Fiesta 1.5/1.6 TDCi Stage V 2013 model year
F-Series Super Duty (platform P473) 6.7 Powerstroke 2017-2018 model year
Transit Connect 1.6 TDCi Stage V 2014 model year
Transit Courier 1.5/1.6 TDCi Stage V 2014 model year+ Service procedure “Reset Differential Pressure Sensor Learned Values” for:
F-Series Super Duty (platform P473) 6.7 Powerstroke 2017-2018 model year
Transit (North America) 2015-2018 model years+ Some configuration parameters
+ Support for HSWM module (aftermarket) for:
Expedition 2017 model year+ Service function “Crash Flag Reset” for BCMii module of:
C-Max (EU) 2015 model year+ Service function “Calibrate Cruise Control Sensors” for CCM module of:
Edge 2011-2012 model years
Explorer 2011-2013 model years
Focus Mk3.5 (EU) 2015 model year
Kuga Mk2 (EU) 2013 model year
Taurus 2010-2013 model years
Transit 2013 model year
Transit Connect 2014 model year
Lincoln MKS 2009-2013 model years
Lincoln MKT 2010-2013 model years
Lincoln MKX 2011-2013 model years+ Service function “ABS Service Bleed” for:
Mazda CX-9 (first generation)+ Service function TCM “Reset All Adaptations” for Mondeo Mk3 with JATCO transmission
+ Service procedures “Reset MAF Sensor Adaptation” for:
Focus Mk3.5 1.5 TDCi Stage VI 2015 model year
Transit Connect 1.5 TDCi Stage VI 2014 model year+ Service function “Reset the High Pressure Fuel System Learned Values” for:
Focus Mk3.5 1.5/2.0 TDCi Stage V/Stage VI 2015 model year
Ka/Figo 1.5 DV5D 2015 model year
Kuga Mk2 2.0 TDCi DW10F Stage V/Stage VI 2013 model year
Mondeo Mk5 1.6 TDCi Stage V 2015 model year
Transit Connect 1.5 TDCi Stage VI 2014 model year* fixes and improvements in Output Control function
– unability to write to RCM Focus Mk3/3.5 (EU)
– Critical bug that allowed to change Central Configuration parameters in a wrong way (without right checksum calculation) on some models, that may cause a “brick” of vehicles with RFA (keyless) ignition
– bug with timeout in service function “Enter Electric Parking Brake Maintenance Mode” and “Exit Electric Parking Brake Maintenance Mode”
– incorrect loading vehicle profile in offline mode for some models
– content bug in in service function “Remote Keyless Entry Programming” for Focus/C-Max Mk2.52.3.15 beta, 2018-05-16 (download)+ Vehicle database update
+ Service function “ABS Service Bleed” for:
Edge 2011-2014 model years
Explorer 2011-2015 model years
Fiesta 2011-2013 model years
Five Hundred 2005-2007 model years
Flex 2009-2012 model years
Taurus 2008-2012 model years
Lincoln MKS 2009-2012 model years
Lincoln MKT 2010-2012 model years
Lincoln MKX 2011-2015 model years
Mercury Montego 2005-2007 model years
Mercury Sable 2008-2009 model years+ Configuration and programming procedure “RCM Module initialization/relearn vehicle data” for:
Transit (EU market) 2006 model year+ Service function “PATS Programming” (only for standart PATS, doesn’t work for cars with keyless system!) for:
Mazda 5/Premacy 2008-2012 model years+ Service function “Enter Electric Parking Brake Maintenance Mode” and “Exit Electric Parking Brake Maintenance Mode” for:
Edge 2015-2018 model years
Escape 2017-2018 model years
Fusion 2013-2018 model years
Galaxy/S-Max 2015 model year
Kuga 2017-2018 model years
Mondeo 2015 model year
Mondeo (China) 2017-2018 model years
Taurus 2016 model year
Lincoln Continental 2017-2018 model years
Lincoln MKC 2015-2019 model years
Lincoln MKX 2016-2018 model years
Lincoln MKZ 2013-2018 model years+ Service function “Calibrate AdvanceTrac/IVD” for:
Fiesta/Fusion 2002/2006 model years
Focus Mk1 2002-2004 model years+ Service function “Crash Flag Reset” for RCM module of:
Galaxy/S-Max 2015 model year+ Some configuration parameters for several models found by our testers
* added function to ask user about Sync version and display only compatible configuration parameters
* added configuration and programming procedures “ABS Module initialization/relearn vehicle data” and “SMS/MRCC Module initialization/relearn vehicle data” to latest gen of Mazda Skyactive (2016+)
* fixes and improvements in Output Control function
* fixes and improvements configuration and programming function “RCM Module initialization/relearn vehicle data” for:
Focus/C-Max Mk3/3.5* fixes and improvement in CAN communication procedure
– RKE key programming bug in service function “Remote Keyless Entry Programming” for:
Galaxy/S-Max 2006/2010 model years
Mondeo Mk4 2007/2011 model years- cluster panic on Focus Mk3.5 because of wrong adressing the TCU module
– invailability PATS programming function for some models of 1996-2005 model years with Virtual Image Cluster (VIC) module
– bug in service function “Crash Flag Reset” for RCM module of CMax 2015 model year (European, after restyling)
– error opening *.ABT file if the folder path contains a dot or several dots2.3.14 beta, 2018-04-11 (download)+ Vehicle database update
+ Ability to enter PCM strategy or part number manually if vehicle is not recognized
+ Configuration and Programming function “PCM Vechile ID block configuration” for certain PCMs
+ Configuration and Programming function “Transmission Characterization Update” for models with 6F, 6R80, 6R140 and HF35 automated transmissions
+ Service function “Remote Keyless Entry Programming” (passive keys programming for models with keyless entry and start, requires adapter with MS-CAN support) for:
Galaxy/S-Max 2006/2010 model years
Mondeo Mk4 2007/2011 model years+ Service function TCM “Reset All Adaptations”, PCM/TCM “Clear Transmission Adaptive Tables” for models with automated transmission after 2005 model year that support it
+ Service function “ABS Service Bleed” for:
Edge 2007-2009 model year
Escape 2008-2012 model years
Expedition 2005-2014 model years
Expedition EL 2007-2014 model years
Explorer 2004-2010 model years
Explorer SportTrac 2007-2010 model years
Freestar 2006-2007 model years (traction control only)
Focus Mk1 (C170) 2008-2011 model years
Focus Mk2/C-Max 2003-2008 model years
Fusion 2006-2012 model years
Mondeo Mk3 2001 model year
Lincoln MKX 2007-2009 model year
Lincoln MKZ 2006-2012 model years
Lincoln Navigator 2005-2014 model years
Lincoln Navigator L 2007-2014 model years
Mercury Mariner 2005-2012 model years
Mercury Milan 2005-2011 model years
Mercury Monterey 2006-2007 model years (traction control only)
Mercury Mountainer 2004-2010 model years
Mercury Zephyr 2006-2012 model years
Mazda Tribute 2005-2012 model years+ Support for HSWM module (aftermarket) for:
Fusion 2013 model years
Mustang 2016-2017 model years* improvements in service function “Remote Keyless Entry Programming” for:
Focus/CMax Mk2 (EU market) 2003/2008 model years
Kuga Mk1 2008 model year* fixes and improvements in CAN communication procedures
* fixes and improvements configuration and programming function “RCM Module initialization/relearn vehicle data” for:
Mondeo Mk4/Galaxy/S-Max 2006-2014* check for B115E:08 in service procedures “Rear camera calibration” and “Local Interconnect Network New Module Calibration”
* reworked OBDII tests – fixes, improvements, added some missing test IDs, added export to text file for OBDII Mode 6 test etc
– bug in service function “Crash Flag Reset” for RCM module of Focus Mk3.5 (European)
– hanging FORScan during connection to 2018 IPMB
– incorrect interpetation DTCs in OBDII modules in some cases2.3.13 beta, 2018-02-02 (download)+ Vehicle database update
+ Ability to load previously stored vehicle profile in case of connection to vehicle cannot be established
+ Service function “Calibrate Steering Angle Sensor” for:
Escape /Tribute / Mariner Hybrid 2010-2012 model year+ Service functions “Calibrate Lateral Acceleration Sensor” for:
Transit 2006 model year+ Service functions “Calibrate Longitudinal Sensor” for ABS of:
Ecosport 2012-2013 model years (not all ABS types)
Edge 2011-2014 model years
Explorer 2011-2015 model years
Fiesta (North America) 2011-2013 model years
Lincoln MKX 2011-2015 model years+ Service function “Crash Flag Reset” for RCM modules of:
Mondeo Mk5 2015 Model year+ Configuration parameters “Daytime running lights” and “Global Open” for GEM/SJB module of:
Fusion 2010 model year
Mercury Milan 2010 model year
Lincoln MKZ 2010 model year (thanks to Ivo H)+ Service function “PATS Programming” (only standard PATS, not keyless/start button) for:
CMax (North America market) 2013-2016 model years
Focus Mk3 (North America market) 2012-2014 model years
Escape 2.3 Hybrid 2006-2007 model years
Escape (North America market) 2013-2016 model years
Fusion (North America market) 2010-2012 model years
Mustang 2010 model year
Taurus 2010-2012 model years
Lincoln MKS 2009-2012 model years
Lincoln MKT 2010-2012 model years
Lincoln MKZ 2010-2012 model years+ Support for CLM module in service function “PATS Programming” for:
Edge 2011-2014 model years
Expedition 2015-2017 model years
Explorer 3.5 TiVCT 2011 model year
Explorer 2012-2015 model years
Flex 2013-2017 model years
Taurus 2013-2017 model years
Lincoln MKS 2013-2016 model years
Lincoln MKT 2013-2017 model years
Lincoln MKX 2011-2015 model years
Lincoln Navigator 2015-2017 model years+ Few PDM, DDM, IPC, BdyCM configuration parameters for:
Mondeo MK5
Fusion 2013-2018 model years
Lincoln MKZ 2013-2018 model years+ Configuration and Programming function “Odometer write” for :
Mondeo Mk5 (EU) 2015 model year+ Parameters to PCM module of Transit 2.0 DOHC SFI 8V 1995 model year
+ Version check
* Automated download of SBL files in Central Configuration function
* Improvements in “Headlamp Alignment And Calibration” function for the following vehciles, equipped with HCM module:
Focus Mk1 200-2002 model year
Focus/CMax Mk2 2003-2008 model year
Kuga 2008 model year* Added text messages for error codes 90-94 in the service function “Fuel Injector Pilot Correction Learn” for:
Transit 2.2/2.4/3.2 TDCi 2006 model year- bug in “Module Initialization” sub-function of service function “Remote Keyless Entry Programming” for:
Focus/CMax Mk2 (EU market) 2003/2008 model years
Kuga Mk1 2008 model year- bug in “Module Initialization” sub-function of service function “PATS programming” for:
Falcon/Fairmont/Fairlane AU
US market models after 2009- some content bugs in Central Configuration
– bug that caused OUT OF MEMORY error in adapters on STN familty integral circuits
– unability to write live stream in CSV format for the module All
– incorrect loading FSL files saved in summarized output mode
– bug in some service functions on Mazda BL with 1.6 Y6 engine
– bug not changing disk letter in Windows x64 in file open dialogs
2.3.12 beta, 2017-10-11 (download)+ Force write confirmation in procedure “Module configuration (AS BUILT format)” to provide an ability to re-write module configuration when no changes are made
+ Service procedures “Reset EGR Valve Adaptations”, “Reset the Intake Air Throttle Valve Learned Values”, “Reset Charge Air Cooler Bypass Valve Position Offset” for:
Mazda 3 BK 1.6 Y6 2003-2009+ Service functions “Calibrate Longitudinal Sensor” for ABS of:
Everest 2015 model year
F-150 2015-2018 model years
F-Series Super Duty 2017-2018 model year
Ranger 2015 model year+ Configuration and Programming function “Odometer write” for :
B-Max 2012 model year
Fiesta (EU) 2008/2013 model year
Fiesta (US) 2011-2017 model years
Ecosport (EU) 2014 model year- crash in Demo mode
– programming functions optimization added in 2.3.11 for slow adapters that seem not compatible with some modules
– bug in J2534 protocol implementation – support for HS2/HS3 CAN presence service
– missing configuration parameters for IPC and BdyCM module of Everest 2015 model year (added in 2.3.11 but didn’t really work)
– bug in some communications over OBDII for adapters on STN chip2.3.11 beta, 2017-10-01 (download)+ Vehicle database update
+ Service procedure “Battery Monitoring System Reset” for:
CMax (European market) 2011-2015 model years+ Service function “Read Factory Keyless Entry code” for:
Edge 2007-2010 model years
Escape / Mariner Hybrid 2005-2007 model years
Escape 2005-2007 model years
Explorer 2006-2010 model years
Explorer SportTrac 2007-2010 model years
Expedition/EL 2007-2014 model years
Focus Mk1 (platform C170) 2008-2011 model year
Five Hundred 2005-2007 model years
Flex 2009 model year
Freestyle 2005-2007 model years
F-150 2009-2010 model years
F-Series Super Duty 2008-2010 model year
Fusion 2006-2011 model years
Sable 2008-2009 model years
Taurus/X 2008-2009 model years
Maverick 2005-2007 model years
Mercury Milan 2006-2011 model years
Mercury Mariner 2005-2007 model years
Mercury Mountainer 2006-2010 model years
Mercury Montego 2005-2007 model years
Mercury Zephyr 2006-2012 model years
Lincoln Navigator/L 2007-2014 model years
Lincoln MKX 2007-2010 model years
Lincoln MKZ 2006-2012 model years
Mazda Tribute 2005-2007 model years+ Service function “ABS Service Bleed” for:
Escape Hybrid 2.3 HEV 2005-2008 model years
Mercury Mariner Hybrid 2.3 HEV 2005-2008 model years+ Service function “Calibrate Cruise Control Sensors” for CCM module of:
Edge 2013-2018 model years
Escape/Kuga 2017-2018 model years
Explorer 2014-2017 model year
Everest 2015 model year
F-150 2015-2018 model years
Flex 2014-2018 model years
F-Series Super Duty 2017-2018 model year
Fusion 2013-2018 model years
Galaxy/SMax 2015 model year
Kuga Mk3 (EU) 2017 model year
Mondeo Mk5 (China) 2015/2017 model years
Mustang 2015-2017 model year
Ranger 2015 model year
Taurus 2014-2018 model years
Lincoln Continental 2017-2018 model years
Lincoln MKC 2015-2018 model year
Lincoln MKS 2014-2016 model year
Lincoln MKT 2013-2016 model year
Lincoln MKX 2013-2018 model years
Lincoln MKZ 2013-2018 model years+ Service procedures “Read Fuel Injector correction factors” and “Change Fuel Injector correction factors” for:
F-Series Super Duty 6.7 Powerstroke 2011-2018 model years
F-650/F-750 6.7 Powerstroke 2016-2018 model years+ PATS programming functions “Enable Unlimited Key mode” and “Disable unlimited key mode” for:
Focus Mk1 (platform C170) 2008-2011 model year
F-150 2009-2010 model year
Escape 2.5/3.0 2009-2010 model years
Escape 2011-2012 model years
Expedition/EL 2009-2014 model year
Mazda Tribute 2.5/3.0 2009-2010 model years
Mazda Tribute 2011-2012 model years
Mercury Mariner 2.5/3.0 2009-2010 model years
Mercury Mariner 2011-2012 model years
Lincoln Navigator/L 2009-2014 model year+ Configuration and programming procedure “ABS Module initialization/relearn vehicle data” for:
Escape/Kuga 2014-2017 model years+ Configuration and programming function “SMS/MRCC Module initialization/relearn vehicle data” for:
Mazda Skyactiv+ Configuration and programming function “PCM Module initialization/relearn vehicle data” for:
C-Max (US Market) 2013-2018 model years
Edge 2011-2014 model years
E-Series 2017 model year
Escort 2015 model year
Expedition 2015-2017 model year
Expedition EL 2015 model year
Explorer 2011-2017 model years
Everest 2.0 Ecoboost 2015 model year
F-650/F-750 2016-2018 model years
F-150 2011-2018 model years
Fiesta (US Market) 2013-2017 model years
Focus (US Market) 2012-2017 model years (except BEV)
Focus (EU Market) gasoline engines 2015 model year
Ford GT 2017 model year
Flex 2013-2018 model years
F-Series Super Duty 2011-2017 model year
Fusion 2013-2018 model years
Galaxy/S-Max gasoline engines 2015 model year
Ka/Figo 2015 model year
Kuga (US market) 2013-2018 model years
Kuga (EU market) 1.5/1.6/2.0 Ecoboost 2013-2017 model years
Mondeo Mk5 2015 gasoline and hybrid engines 2015 model year
Mustang 2015-2017 model year
Ranger 2.5 iVCT 2015 model year
Taurus 2013-2017 model years
Transit (US market) 2015-2018 model year
Transit Connect (US market) 2014-2018 model year
Lincoln Continental 2017-2018 model year
Lincoln MKC 2015-2018 model year
Lincoln MKS 2013-2016 model year
Lincoln MKT 2013-2018 model year
Lincoln MKX 2011-2015 model years
Lincoln MKZ 2013-2018 model years
Lincoln Navigator 2015-2017 model years
Lincoln Navigator L 2015 model year+ Some configuration parameters for IPC and BdyCM module of:
Ranger 2015 model year
Everest 2015 model year(thanks to SAEB – https://www.saeb.net/)
* All configuration and programming functions “Module Reset/Confguration” are renamed to “Module initialization/relearn vehicle data”
* small improvements in ELM327/STN11xx/STN21xx communication procedure (BUFFER FULL error processing)
* fix/improvement in service function “PATS Programming” for:
Focus Mk1 (platform C170) 2008-2011 model year
F-150 2009-2010 model year
Escape 2.5/3.0 2009-2010 model years
Escape 2011-2012 model years
Expedition/EL 2009-2014 model year
Mazda Tribute 2.5/3.0 2009-2010 model years
Mazda Tribute 2011-2012 model years
Mercury Mariner 2.5/3.0 2009-2010 model years
Mercury Mariner 2011-2012 model years
Lincoln Navigator/L 2009-2014 model year- bug in service function “Change Fuel Injector correction factors” for:
Mazda 6 2.0 RF-T 2003-2004 model year
Mazda MPV 2.0 RF-T 2003-2004 model year
Mazda Bongo 2.0 RF-T 2003-2004 model year
Mazda Titan Dash 2.0 RF-T 2003-2004 model year- incorrect recording FSL if more than 255 simulatenous PIDs are added to the profile
– few small bugs in parameters calculation
– incorrect writing central configuration to secondary module instead of primary and vice versa, in some cases
– interrupt of PID reading in summarized output mode for adapters on STN chip
– bug in service function PATS programming->Module Initialization function for:
Mazda 2/Demio DE (2007-2014)
Mazda 3/Axela BL
Mazda 6/Atenza GH (2007-2012)- bug in J2534 communication procedure (related to changes made in 2.3.10)
– Bug in list of Central Configuration parameters for some models (only small part of parameters were displayed)2.3.10 beta, 2017-07-27 (download)+ Vehicle database update
+ Configuration and Programming function “Odometer write” for EU models:
Focus Mk3 2011 model year
Focus Mk3.5 2015 model year
Kuga Mk2 2013 model year
Transit 2014-2018 model year
Transit Connect 2014 model year
Transit Courier 2014 model year+ Service function “Remote Keyless Entry Programming” (passive keys programming for models with keyless entry and start, requires adapter with MS-CAN support) for:
Focus/CMax Mk2 (EU market) 2003/2008 model years
Kuga Mk1 2008 model year+ Service procedure “ABS service bleed” for vehicles with ESP:
B-Max with ABS Mk100 2012 model year
Edge/Galaxy/S-Max 2015 model year
Edge 2015-2018 model years
Explorer 2016-2017
Fiesta Mk7 (EU market) with ABS Mk100 2013 model year
Fiesta (non-EU market) 2014-2017 model years
Fusion (US market) 2013-2018 model years
Mondeo Mk5 (EU market) 2015 model years
Mondeo (China market) 2013-2017 model years
Mustang 2015-2017 model years
Taurus 2016 model year
Lincoln Continental 2017 model year
Lincoln MKC 2015-2018 model years
Lincoln MKX 2016-2017 model years
Lincoln MKZ 2013-2017 model years+ Service function “Crash Flag Reset” for RCM and BCM modules for:
Focus Mk3.5 (EU) 2015 model year+ Service function “PATS Programming” for:
Mazda 6 2.0 RF_T 2002-2004 model year+ Service functions “Calibrate Lateral Acceleration Sensor” for:
C-Max PHEV/FHEV 2013-2017 model year
Focus Mk3 BEV 2012-2017 model year
Fusion 2013-2017 model year
Mustang 2015-2017 model year
Edge 2015-2018 model year
Explorer 2016-2017 model year
Galaxy/SMax 2015 model year
Taurus 2016 model year
Lincoln Continental 2017 model year
Lincoln MKC 2015-2018 model year
Lincoln MKX 2016-2017 model year
Lincoln MKZ 2013-2017 model year+ Service functions “Lane Departure Warning System Camera calibration” for:
Edge 2015-2018 model year
Everest 2015 model year
Explorer 2013-2017 model year
F-150 2015-2018 model year
Focus 2015-2017 model year
F-Series Super Duty 2017-2018 model year
Fusion 2013-2018 model year
Galaxy/SMax 2015 model year
Kuga 2017-2018 model year
Mondeo (China market) 2013-2017 model year
Mondeo (EU market) 2015 model year
Ranger 2015 model year
Taurus 2014-2017 model year
Transit (US market) 2015-2018 model year
Transit (EU market) 2016 model year
Transit Connect (US market) 2016-2018 model year
Lincoln Continental 2017-2018 model year
Lincoln MKC 2013-2016 model year
Lincoln MKS 2013-2016 model year
Lincoln MKT 2013-2016 model year
Lincoln MKX 2016-2018 model year
Lincoln MKZ 2013-2018 model year+ Service function “IPMB Local Interconnect Network New Module Calibration” (used for forward camera calibration) for:
F-150 2015-2018 model year
F-Series 2017-2018 model year
Galaxy/S-Max 2015 model year
Kuga (EU market) 2013-2017 model year
Edge 2015-2018 model year
Explorer 2016-2017 model year
Lincoln Continental 2017-2018 model year
Lincoln MKX 2015-2018 model year
Lincoln MKZ 2018 model year+ Service procedures “Camshaft Position Reference Adaption Learn” for EU models:
B-Max 1.0 Ecoboost 2012 model year
EcoSport 1.0 Ecoboost 2014 model year
Fiesta 1.0/1.6 Ecoboost 2013 model year
Focus/CMax Mk3 1.0/1.6 Ecoboost 2011 model year
Focus Mk3.5 2.0 TDCi StgV/StgVI 2015 model year
Galaxy/S-Max 1.6/2.0 Ecoboost 2006/2010 model years
Galaxy/S-Max 2.0 TDCi 2015 model year
Kuga Mk2 2.0 TDCi StgV/StgVI 2013 model year
Kuga Mk2 1.6 Ecoboost 2013 model year
Mondeo Mk4 1.6/2.0 Ecoboost 2007/2011 model years
Mondeo Mk5 2.0 TDCi StgV/StgVI 2015 model year
Transit Connect 1.0 Ecoboost 2014 model year
Transit Courier 1.0 Ecoboost 2014 model year+ Service procedures “Read Fuel Injector correction factors” and “Change Fuel Injector correction factors” for (not all of PCM supports it!):
Mazda 6 2.0 RF-T 2003-2004 model year
Mazda MPV 2.0 RF-T 2003-2004 model year
Mazda Bongo 2.0 RF-T 2003-2004 model year
Mazda Titan Dash 2.0 RF-T 2003-2004 model year+ PCM hardware type detection
+ Check if module firmware update is available (so far it works only for new Ford and Lincoln models)
+ Check for Visteon PCM DPC-805, DPC-806, DPC-808, DPC-812, DPC-813 that do not support reading PIDs from FIP module)
+ some tuned PCMs to database
* minor improvements in J2534 communication procedure
– bug in accessing Central Configuration on Transit/Tourneo Connect 2012 model year
– incorrect processing Configuration and Programming function “RCM module reset/configuration” for certain versions of Mondeo Mk4 RCM module
– bug writing As Built Data on some modules of newest cars (ex. 2017 F-450 IPC)
– PATS Programming function failure on F-350 2008 (may affect other models with the same PATS)
– bug in coded access procedure for some models of:
Mazda 2 (Japan) 2002-2005 model years
Mazda 6/Atenza 2002-2008 model years- incorrect work of service procedure “DPF Static Regeneration” for F-Series Super Duty (platform P473) 6.7 Powerstroke 2011-2016 model year in case of Imperial measurement units
– bug in Output Control mode appeared for some parameters
– incorrect reading central configuration block on some china adapters with slow interface
– incorrect displaying As Built block if the block is too large for As Built format
– bug disappearing service function “Reset All Adaptations” for some EU vehicles
– content bugs in Central Configuration list2.3.9 beta, 2017-05-25 (download)+ Vehicle database update
+ Configuration and programming procedures “ABS Module reset/configuration” for:
Falcon 2011-2014 model year
Kuga (European market) 2013 model year
Ranger (P375) 2011 model year
Territory 2011-2014 model year+ Service function “PATS Programming” (only for standart PATS, doesn’t work for cars with keyless system or CLM module!) for:
Edge 2011-2014 model years
Expedition 2015-2017 model years
Explorer 3.5 TiVCT 2011 model year
Explorer 2012-2015 model years
Flex 2013-2017 model years
Taurus 2013-2017 model years
Lincoln MKS 2013-2016 model years
Lincoln MKT 2013-2017 model years
Lincoln MKX 2011-2015 model years
Lincoln navigator 2015-2017 model years+ Service function “PATS Programming” (only for standart PATS, doesn’t work for cars with keyless system!) for:
Fiesta (US market) 2011-2017 model years
Mazda 2/Demio DE (2007-2014)
Mazda 3/Axela BL (2008-2013) – requires adapter with MS-CAN support
Mazda 6/Atenza GH (2007-2012) – requires adapter with MS-CAN support+ Service function “PATS Programming” (only for cars without SCLM! Please contact us if you get SCLM error) for:
Thunderbird 2003-2005 model years
Lincoln LS 2003-2006 model years+ Service procedures “Read Fuel Injector correction factors” and “Change Fuel Injector correction factors” for:
Transit Custom (EU market) 2.0 TDCi StgVI 2016 model year+ Service function “Tire Pressure Monitor learning mode” for:
Ecosport 2012-2013 model year
Edge/Galaxy/S-Max 2015 model year
Edge (non_EU market) 2015-2017 model year
Escape/Kuga (non-EU market) 2014-2017 model year
Everest 2015 model year
Explorer 2016-2017 model year
F-150 2015-2017 model year
F-Series Super Duty 2017 model year
Focus/CMax (non-EU market) 2014-2017 model year
Fusion 2013-2017 model year
GT 2017 model year
Mondeo Mk5 2015 model year
Mustang 2015-2017 model year
Kuga (EU market) 2017 model year
Ranger 2015 model year
Taurus 2016 model year
Transit (non-EU market) 2015-2017 model year
Transit Connect (non-EU market) 2014-2017 model year
Transit Custom (EU market) 2016 model year
Lincoln Continental 2017 model year
Lincoln MKC 2015-2017 model year
Lincoln MKX 2016-2017 model year
Lincoln MKZ 2013-2017 model year+ Service function “Read Factory Keyless Entry code” for:
Edge 2011-2014 model year
Expedition 2015-2017 model year
Explorer 2011-2015 model year
F-150 2011-2014 model year
F-650/F-750 2016-2017 model year
Flex 2013-2017 model year
F-Series Super Duty 2011-2016 model year
Taurus 2013-2017
Lincoln MKS 2013-2016
Lincoln MKT 2013-2017
Lincoln MKX 2011-2015
Lincoln Navigator 2015-2017+ Service function “Crash Flag Reset” for RCM module of:
Bantam 2009 model year
Figo 2010-2011 model years
Fiesta 2002-2006 model years
Fusion 2002-2006 model years
Ikon 2010-2011 model years
Transit 2006 model year
Mazda 2 (European market) 2002-2006 model years+ Service function “ABS Service Bleed” for:
Focus Mk3.5 2015 model year
Focus CMax 2016 model year
Transit 2006-2017+ OBDII mode 6 tests for CAN vehicles
+ Support UBP protocol for VCMII adapters
* improvements in AsBuilt Data (ABD) detection
* workaround to recognize some Mustangs with tuned PCMs
– bug in “PATS Programming” service function for Expedition/EL 2009-2014 model year
– incorrect connection to FIP module in data logger/dashboard
– “Unable to identify the vehicle” error for some new Mazda models
– bug in service function “Reset Differential Pressure Sensor Learned Values” for Mondeo 4 and other models with TDCi engine
– bug reading DTCs in MS-CAN modules after DTC reset on J2534 adapters
– incorrect reading central configuration block on some china adapters with slow interface
– incorrect processing/displaying P0000 DTC
– small bug in Central Configuration writing for Ranger 2011 model year
– small bug in communication procedure (appear sometimes on buggy BT and WiFi adapters)2.3.8 beta, 2017-03-24 (download)+ Czech language
+ Slovak language
+ Aggregated PIDs output (simultaneous reading PIDs from different modules)
+ Built-in PATS outcode/incode generator (only for cars before 2011-2012 model years). Thanks to pawel_1980!
+ Service procedures “Read Fuel Injector correction factors” and “Change Fuel Injector correction factors” for:
EdgeGalaxyS-Max 2.0 TDCi 2015 model year
Focus Mk3.5 1.5/1.6/2.0 TDCi 2015 model year
Fiesta 1.5 TDCi 2013 model year
Kuga Mk2 2.0 TDCi (DW10F) 2013 model year
Mondeo Mk5 1.6/2.0 TDCi 2015 model year
Transit Courier 1.5/1.6 TDCi 2014 model year+ Support for FCDIM module As Built Data
+ Service procedure “DPF Static Regeneration”, “Reset the Diesel Particulate Filter Learned Values”, “Reset Differential Pressure Sensor Learned Values” for:
Focus Mk3.5 1.5 TDCi 2015 model year
Fiesta 1.5 TDCi 2013 model year
Transit 2.2 TDCi (Stage VI) 2014-2017 model years+ Service procedure “Reset the Diesel Particulate Filter Learned Values” for:
F-Series Super Duty (platform P473) 6.7 Powerstroke 2011-2016 model year+ Service functions “Reset Differential Pressure Sensor Learned Values”, “Reset the water in fuel warning indicator”, “Reset the Fuel Metering Valve learned values” for:
Kuga 2.0 TDCi (SID-206) 2008 model year
+ Service function “Reset EGR Valve Adaptations” for:
Focus Mk3.5 1.5/1.6/2.0 TDCi 2015 model year
Fiesta 1.5 TDCi 2013 model year
Kuga Mk2 2.0 TDCi (DW10F) 2013 model year+ Injector code checksum test in service function “Change Fuel Injector Correction Factors” for:
Transit 2.2/2.4/3.2 TDCi 2006 model year
+ EGT13 PID for Kuga 2.0 TDCi 2013 model year
+ Added numeric error code to the error output of the service function “Fuel Injector Pilot Correction Learn” for Transit 2.2/2.4/3.2 TDCi 2006 model year
+ Service function “Crash Flag Reset” for RCM module of:
B-Max 2012 model year
Focus/C-Max Mk1
Kuga Mk1* improvements in DTC reset function
* Write All button in Module Configuration (As Built format) now throws a warning about complete configuration rewriting
* fixes and improvements in service function “PATS Programming” for:
Fusion (US market) 2010-2012 model year
Milan 2010-2012 model year
Mustang 2011-2014 model year- incorrect Central Configuration’s checksum calculation on Kuga 2017 (may affect other models too)
– bug in loading *.CCT files with complex file names
– incorrect MS-CAN setup in CanTieCar adapter, FORScan mode
– some content and translation bugs
– bug in calculation some Output Control PIDs2.3.7 beta, 2017-02-13 (download)+ Vehicle database update
+ Configuration and programming procedures “Central configuration”, “RCM Module reset/configuration”, “ABS Module reset/configuration” for:
Focus C-Max 2015 model year+ Service function “PATS Programming” for:
Focus Mk1 (platform C170) 2008-2011 model year
F-150 2009-2010 model year
Escape 2.5/3.0 2009-2010 model years
Escape 2011-2012 model years
Expedition/EL 2009-2014 model year
Mazda Tribute 2.5/3.0 2009-2010 model years
Mazda Tribute 2011-2012 model years
Mercury Mariner 2.5/3.0 2009-2010 model years
Mercury Mariner 2011-2012 model years
Lincoln Navigator/L 2009-2014 model year+ Service procedure “DPF Static Regeneration” for:
F-Series Super Duty (platform P473) 6.7 Powerstroke 2011-2016 model year+ Service procedure “DPF Static Regeneration”, “Reset the Diesel Particulate Filter Learned Values”, “Reset Differential Pressure Sensor Learned Values” for:
Transit 2.2 TDCi 2014-2016 model year+ Service function “Calibrate Steering Angle Sensor” for:
Transit 2006 model year+ Service functions “Calibrate Lateral Acceleration Sensor”, “Calibrate Steering Angle Sensor” for ABS/ESP module of:
C-Max 2015 model year+ Service functions “Calibrate Longitudinal Sensor” for ABS/ESP module of:
Focus/C-Max 2015 model year+ Service function “Reset Straight Ahead Angle Learned Value” for:
C-Max 2015 model year+ Service function “Calibrate AdvanceTrac/IVD” for:
Expedition 2003-2004 model year
Explorer 2002-2003 model year
Lincoln Aviator 4.6 4V 2003-2005 model year
Lincoln Navigator 2003-2004 model year
Mercury Mountainer 2002-2003 model year+ Service function “Reset All Adaptations” for:
Galaxy/S-Max 2.0/2.3 Duratec-HE 2006-2010 model year
Mondeo Mk4 2.0/2.3 Duratec-HE 2007-2011 model year
Transit 2.3 Duratec-HE 2006 model year+ Service function “ABS Service Bleed” for:
Expedition 2003-2004 model year
Explorer 2002-2003 model year
Thunderbird 2002-2005 model year
Lincoln Aviator 2003-2005 model year
Lincoln LS 2000-2006 model year
Lincoln Navigator 2003-2004 model year
Mercury Mountainer 2002-2003 model year* fixes and improvements in service function “PATS Programming” for:
F-150 2011-2014 model year
F-Series Super Duty (platform P473) 2011-2015 model year- bug missing Instrument Cluster on Mazda CX-5 and some other Skyactive
– major bug opening Motorcraft *.ab files in programming procedure “Central Configuration” for cars with SBL
– major bug in CAN communication appeared sometimes on programming requests to slow modules
– bug opening *.fsl files that contain non-ASCII characters in the path using Windows file association mechanism (in Windows Explorer or other shell)
– bug in service function “Calibrate AdvanceTrac/IVD” for:
Explorer 2004-2005 model year
Explorer SportTrac 4.0 V6 2005
Mercury Mountainer 2004-2005 model year- bug in EGR reset function for Focus/CMax Mk2
– incorrect output for some error codes in service function “Fuel Injection Pump Learn” for Transit 2006 model year2.3.6 beta, 2017-01-07 (download)+ Service function “Calibrate Cruise Control Sensors” for CCM module of:
Mondeo Mk5 2015 model year+ Service function “PATS Programming” (doesn’t work for cars with keyless system!) for:
Mazda 3 (Europe) 2006 model year
Mazda 3/Axela (Japan) 2006 model year
Mazda 3 (North America) 2007-2009 model year
Mazda 3 (China) 2007 model year
Mazda CX-7 (North America, Japan) 2007-2008 model year
Mazda CX-7 (Europe) 2006 model year
Mazda CX-9 (North America) 2007-2011 model year
Mazda Biante 2008-2012 model year+ Service function “Rmode Rebalance” (battery rebalance) for:
Escape /Tribute / Mariner Hybrid 2005-2012 model year+ Service function “Calibrate Steering Angle Sensor” for:
Escape /Tribute / Mariner Hybrid 2008-2009 model year+ Windows file association for *.fsl files. Now, *.fsl files can be opened from Windows Explorer or any other shell just by mouse double-click
* fixes and improvements in As Built management functions
– bug saving Central Configuration appeared on some adapters built on STN chip
– bug accessing As Built Data for some modules of pre-CAN vehicles. appeared in version 2.3.5
– unability to recognize cars with Ford Performance Power Pack 2 applied
– loss of synchronization reading live data from OBDII module in case of CAN bus errors

Click to enlarge

Back to products

ELS27 Diagnostic Cable for Ford/Mazda PIC24HJ128GP for FORScan

Name: ELS27 Diagnostic Cable for Ford/Mazda PIC24HJ128GP for FORScan - Auto Tools SA
Brand: ford diagnostic cable
SKU: AU_5779828898
Price: 899.00 ZAR
Availability: InStock

R899,00

Add to wishlist

Description

Additional information

Weight	1 kg
Dimensions	15 × 16 × 3 cm

Shipping & Delivery

SHIPPING & DELIVERY

Orders are shipping by The Courier Guy to any address within South Africa. Shipping cost includes insurance up to R1000 unless specified otherwise. Or You can select to have orders delivered by means of Courier or you can select to collect your order from our premises in Cape Town.

DELIVERY TIMES

Shipping within Cape Town typically take working day
Shipping to major centres typically take 1 – 2 working days.
Shipping to smaller centres typically take 3 – 4 working days.
Shipping to outlying areas typically take 4 – 5 working days.

SHIPPING RATES

National Economy Road Freight up to 15Kg - R86.25 (R75 + VAT)
National Overnight Courier up to 2kg - R132.25 (R115 + VAT)
National Overnight Courier over 2kg add R40 per extra 1kg
Cape Town Overnight Courier - R74.75 (R65 + VAT)
